Using the Configuration Interface
23 D-Link Systems, Inc.
L2TP WAN Mode
A method of connection that requires you to enter your L2TP IP Address, L2TP Subnet Mask,
L2TP Gateway IP Address, L2TP Server IP Address, Username and Password (provided by
your Internet Service Provider) to gain access to the Internet.
Enter the IP Address provided by your ISP.
Enter the Subnet mask provided by your ISP.
Enter the Gateway address provided by your ISP.
Enter the IP address of the L2TP server you are connecting to. This
information is provided by your ISP.
The username that you use to login to your Internet connection.
Enter the password associated with your username.
Retype the password for verification.
Defines how long the machine can be idle before the L2TP connection is
disconnected.
The Disconnect button will immediately terminate any active connection.
Note: These buttons become enabled after the router has been rebooted
with the L2TP mode selected.
LAN
Your internal network settings are configured based on the IP Address and Subnet Mask assigned
in this section. The IP address is also used to access this Web-based management interface. It is
recommended that you use the default settings if you do not have an existing network.
LAN Settings
The IP address of the router on the local area network. The local network
settings are based on the address assigned here.
The subnet mask of your router on the local area network.
Used with multiple routers to broadcast routing information.
This option is used if you have multiple routers.
IP Address:
Default Subnet Mask:
RIP Announcement:
Gateway Metric:
L2TP IP Address:
L2TP Subnet Mask:
L2TP Gateway IP
Address:
L2TP Server IP
Address:
User Name:
Password:
Verify Password:
Maximum Idle Time:
L2TP Connection:
Basic > LAN
Basic > WAN > L2TP
