Using the Configuration Interface
28 D-Link Systems, Inc.
WPA-Personal
This option uses Wi-Fi Protected Access with a Pre-Shared Key (PSK).
The key is entered as a pass-phrase of up to 63 characters in ASCII format
at both ends of the wireless connection. The pass-phrase cannot be shorter
than 8 characters. The pass-phrase is used to generate session keys that
are unique for each wireless client.
The encryption algorithm used to secure the data communication. TKIP
(Temporal Key Integrity Protocol) provides per packet key generation and
is based on WEP. AES (Advanced Encryption Standard) is a very secure
block based encryption.
The amount of time before the group key used for broadcast and multicast
data is changed.
WPA-Enterprise
This option works with a RADIUS server to authenticate wireless clients. Wireless clients should
have established the necessary credentials before attempting to authenticate to the Server through
the Gateway. Furthermore, the RADIUS Server may need to be configured to allow this Gateway
to authenticate users.
The method in which the pre-shared key is changed.
The amount of time before the group key used for broadcast and multicast
data is changed.
Amount of time before a client is required to re-authenticate.
The IP address of the authentication server.
The port number used to connect to the authentication server.
A passphrase that must much with the authentication server.
If this is selected then the user will need to connect from the same computer
whenever logging into the wireless network.
Pre-Shared Key:
Cipher Type:
Group Key Update
Interval:
Cipher Type:
Group Key Update
Interval:
Authentication
Timeout:
RADIUS Server IP
Address:
RADIUS Server Port:
RADIUS Server Shared
Secret:
MAC Address
Authentication:
