Using the Configuration Interface
30 D-Link Systems, Inc.
Add/Edit Virtual Server
Name of the virtual server, such as Web Server.
The IP address of the system on your internal network that will provide the
virtual service, such as 192.168.0.50.
Select the protocol used by the service.
The port that will be used on your internal network.
The port that will be accessed from the Internet.
Select a schedule for when this rule is in effect. If you do not see the schedule
you need in the list of schedules, go to the Tools -> Schedules screen and
create a new schedule.
Saves the new rule or modified existing rule to the Rules list. When you are
done editing the settings, you must click the Save Settings button at the top
of the page to make the changes effective and permanent.
Virtual Servers List
Entries on this list can be enabled/disabled by toggling the Enable checkbox. Entries can be modified
by clicking on the paper and pencil icon. To delete an entry, click on the trash can icon. After you’ve
completed all modifications or deletions, you must click the Save Settings button at the top of the
page to save your changes. The router must reboot before new settings will take effect. You will
be prompted to Reboot the Device or Continue. If you need to make additional settings changes,
click Continue. If you are finished with your configuration settings, click the Reboot the Device
button.
Virtual Server Rule:
IP Address:
Protocol:
Private Port:
Public Port:
Schedule:
Save:
