D-Link DGL-4300 Network Router User Manual



Using the Configuration Interface
54 D-Link Systems, Inc.
Sent:
Received:
TX Packets Dropped:
RX Packets Dropped:
Collisions:
Errors:
Sent:
Received:
TX Packets Dropped:
RX Packets Dropped:
Collisions:
Errors:
Sent:
Received:
TX Packets Dropped:
Errors:
LAN Statistics
The number of packets transmitted to the local area network.
The number of packets received from the local area network.
The number of transmit packets dropped on the local area network.
The number of receive packets dropped on the local area network.
The number of collisions on the local area network.
The number of errors occuring on the local area network.
WAN Statistics
The number of packets transmitted to the Internet.
The number of packets received from the Internet.
The number of transmit packets sent to the WAN port that were dropped.
The number of receive packets sent to the WAN port that were dropped.
The number of collisions involving packets intended for the WAN port.
The number of errors occuring with packets intended for the WAN port.
Wireless Statistics
The number of packets sent to the wireless network.
The number of packets received from the wireless network.
The amount of transmit packets dropped.
The number of errors relating to packets to/from the wireless network.
Active Sessions
The Active Session page displays the full details of active sessions to your router.
