FS-8700-41 Simplex 4100 Driver Manual Page 16 of 58
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-2296 Toll_Free: 888-509-1970 email: support@fieldserver.com
4.5.4. Protocol (Simplex Device) Specific Parameters
Column Title Function Legal Values
sim4100_func
A keyword which controls the function being
performed or the type of data being polled /
written.
Further notes on
these keywords
are provided in
Appendix A
Ackall, Setd,
Disable, Restart,
Clistall, Clist,
Time, Ctime,
Ack,
Xpoint, Seta,
Super, Show,
Earths, Value,
ClearAll
The Simplex Time Recorder Company - 4100 Computer Port Protocol only uses the
standard 4100 address format of <Card>-<Point>-<Sub-point>. Symbolic addressing is
not supported. The following keywords are used to address devices.
sim4100_Card Simplex Address <Card>
sim4100_Point Simplex Address <Point>
sim4100_Sub Simplex Address <Sub_Type>
Further notes
and examples
are provided in
Appendix A
sim4100_WriteThru*
Only appropriate when the
sim4100_func=clist.
Controls the write through behavior of the
clist function. See Appendix A.20 for
additional information.
When using the default value then the write
commands are done using the format SET
c-p-s ON/OFF. If the parameter is set to
value then writes are done using the format
SET c-p-s value.
Onoff, value
Store_Unsolicited*
Control the ability of ‘CLIST’ map descriptors
to be used to store data from unsolicited
messages. Refer also to Appendix A.20
Yes/No
