3 Installing the Adapter in the
NetServer
NOTE If you are replacing an existing adapter with
the HP NetServer 10/100 adapter in
Windows NT, see the section Removing an
Existing Adapter in Windows NT in Chapter
10, "Technical Information," later in this
guide.
1. Shut down Windows (if it’s running) by clicking the Start
button, and then clicking Shut Down.
2. Turn off the server and unplug the power cord. Then
remove its cover.
WARNING Turn off and unplug power to the server
before removing its cover. Failure to do so
could shock you and may damage the
adapter or server.
3. Remove the cover bracket from a PCI busmaster adapter
slot by unscrewing the screw that secures it. Most
computers have busmaster-enabled slots. If you have
configuration problems, see your computer’s
documentation to determine if the PCI slots are
busmaster-enabled.
4. If you want to enable the Wake On LAN feature, see the
Connect the Wake On LAN Power Cable section in
Chapter 4, "Connecting the Network Cable," later in this
guide before completing the rest of these steps.
5. Insert the HP NetServer 10/100 adapter into a PCI slot and
push it into the slot until it’s firmly seated. Then secure the
adapter bracket with the screw you removed in step 3.
6. Replace the server cover and plug in the power cord.
