Datasheet 109
Processor Land Listing
D10 DDR3_DQS_DP[04] SSTL I/O
D12 DDR3_DQ[32] SSTL I/O
D14 DDR3_ODT[4] SSTL O
D16 DDR3_CS_N[8] SSTL O
D18 DDR3_MA[10] SSTL O
D2 VSS GND
D20 DDR3_MA[04] SSTL O
D22 DDR3_MA[08] SSTL O
D24 DDR3_MA[14] SSTL O
D26 VSS GND
D32 DDR3_DQ[18] SSTL I/O
D34 DDR3_DQS_DP[11] SSTL I/O
D36 VSS GND
D38 DDR3_DQS_DP[00] SSTL I/O
D4 TEST3 O
D40 DDR3_DQ[05] SSTL I/O
D42 DMI_TX_DN[0] PCIEX O
D44 DMI_TX_DN[2] PCIEX O
D46 RSVD
D48 DMI_RX_DN[1] PCIEX I
D50 DMI_RX_DN[3] PCIEX I
D52 PE1A_RX_DP[1] PCIEX3 I
D54 PE1A_RX_DP[2] PCIEX3 I
D56 RSVD
D6 DDR3_DQ[53] SSTL I/O
D8 VSS GND
DA11 VSS GND
DA17 DDR1_CKE[3] SSTL O
DA19 DDR1_MA[09] SSTL O
DA21 DDR1_CLK_DN[3] SSTL O
DA23 DDR1_MA[03] SSTL O
DA25 DDR1_ODT[1] SSTL O
DA27 DDR1_CS_N[9] SSTL O
DA29 DDR1_CS_N[6] SSTL O
DA3 VSS GND
DA31 DDR1_DQ[44] SSTL I/O
DA33 DDR1_DQ[40] SSTL I/O
DA35 DDR1_DQ[43] SSTL I/O
DA37 DDR1_DQ[60] SSTL I/O
DA39 DDR1_DQ[62] SSTL I/O
DA41 VSS GND
DA43 VSS GND
DA45 VSS GND
DA47 VSS GND
Table 8-2. Land List by Land
Number (Sheet 29 of
Land
No.
Land Name
Buffer
Type
Direction
DA49 VTTA PWR
DA5 VSS GND
DA51 VSS GND
DA55 SAFE_MODE_BOOT CMOS I
DA57 RSVD
DA7 DDR1_DQ[08] SSTL I/O
DA9 VSS GND
DB10 DDR1_DQ[14] SSTL I/O
DB12 VSS GND
DB14 DDR1_DQS_DN[17] SSTL I/O
DB18 DDR1_MA[14] SSTL O
DB2 VSS GND
DB20 DDR1_MA[08] SSTL O
DB22 DDR1_MA[04] SSTL O
DB24 DDR1_CS_N[0] SSTL O
DB26 DDR1_BA[0] SSTL O
DB28 DDR1_RAS_N SSTL O
DB30 DDR1_MA[13] SSTL O
DB32 VSS GND
DB34 DDR1_DQS_DP[05] SSTL I/O
DB36 VSS GND
DB38 DDR1_DQS_DP[16] SSTL I/O
DB4 TEST0 O
DB40 DDR1_DQ[59] SSTL I/O
DB56 RSVD
DB58 VSS GND
DB6 DDR1_DQ[13] SSTL I/O
DB8 DDR1_DQS_DN[10] SSTL I/O
DC11 DDR1_DQ[10] SSTL I/O
DC15 DDR1_DQS_DP[08] SSTL I/O
DC17 DDR1_MA[15] SSTL O
DC19 DDR1_MA[12] SSTL O
DC21 DDR1_CLK_DP[3] SSTL O
DC23 DDR1_MA[00] SSTL O
DC25 DDR1_BA[1] SSTL O
DC3 VSS GND
DC33 DDR1_DQS_DP[14] SSTL I/O
DC35 DDR1_DQ[42] SSTL I/O
DC37 DDR1_DQ[61] SSTL I/O
DC39 DDR1_DQS_DP[07] SSTL I/O
DC41 VSS GND
DC5 VSS GND
DC55 RSVD
DC7 DDR1_DQ[09] SSTL I/O
Table 8-2. Land List by Land
Number (Sheet 30 of
Land
No.
Land Name
Buffer
Type
Direction
