Stationary Installation
RFM-4200-5015 Rev1
31
Mounting the Antenna(s)
The location of the antenna should be chosen carefully.
!
Important things to consider when installing the
antenna equipment.
• Installation of recommended equipment must be
installed in accordance with Nextel’s installation
instructions.
• To assure compliance with United States FCC
regulations on RF exposure, equipment must be
installed in such a way as to maintain a separation
of at least 8 inches (20 cms) between the antenna
and the human body.
• Ensure that the antenna is properly installed
external to the vehicle and in accordance with the
requirements of the antenna manufacturer/supplier.
• Use only an approved antenna. Unauthorized
antennas, modifications or attachments could
impair call quality, damage the modem, or result in
the violation of FCC mandates.
Approved Antennas
The following table states the approved antennas that can be used with the
iR1200 modem.
Part No. Description
5000-C5-RFM Mag Mount Cellular Antenna
5030-C5-RFM Mag Mount GPS Antenna
NOTE: Antennas with gain exceeding 3db do not comply with FCC RF
exposure and are not allowed for use with this product.
