Stationary Installation
RFM-4200-5015 Rev1
35
Connect Antenna Cables
The following table describes the steps for connecting antenna cables to the
modem (use only an approved antenna – see list of Approved Antennas on page
31):
1 Insert the male end of the modem antenna cable to the
connector labeled MODEM ANT on the modem.
2 Insert the male end of the GPS antenna (optional) cable to
the connector labeled GPS ANT on the modem.
Connect Data Cables
The iR1200 modem can be connected to the host DTE equipment using a
standard “straight through” 9-pin male to a 9-pin female serial cable.
The following step describes how to connect the data cable:
Connect the 9-pin male end of the cable to the iR1200
communication connector and the 9 pin female end of the cable
to the data terminal equipment (DTE).
