1
Chapter 1
Introduction
With the innovative IP-based technology, PLANET has turned the conventional
KVM switches into networking devices. The IKVM-1000 captures, digitizes and
compresses video signal, then transmits it with keyboard and mouse signals
through IP network. Multiple remote sites can monitor the same PC server simulta-
neously. With SSL authentication and data encryption, the IKVM-1000 provides a
non-intrusive solution for remote access and control. The remote access and
control software operates on its embedded processors only, but not on mission-
critical servers, so that there is no interference with server operation or decrease
on the network performance.
1.1 Features
Ø Locally attaches to an analog KVM, Server or PC and remote login for admini-
stration
Ø Ethernet port interface for LAN/WAN access
Ø Controls any PC/Server anywhere from anyplace
Ø Local console and fast remote Web browser access, Fast redirection and Ani-
mation
Ø Remote VGA resolution up to 1280 X 1024
Ø Cascade to regular non-IP based KVM switch to share the same TCP/IP port
Ø SSL authentication connection and video data encryption
Ø Single or multiple user access one target server
Ø Easy to set-up and non-intrusive Installation
1.2 Package Contents
The following items should be included:
• IKVM-1000
• Null Modem Cable
• Mounting Bracket
• Quick Installation Guide
• CD-ROM
• Power Adapter
If any of the above items are damaged or missing, please contact your dealer
immediately.
1.3 Specifications
Model IKVM-1000
Supported Protocol HTTP, HTTPS, SSL, TCP/IP, Telnet, SNMP
Local Console Con-
nectors (all female
type)
PS/2 keyboard port
PS/2 mouse port
DB-15 VGA port
Remote Console RJ-45 port
1
