For using the Remote Console window of your managed host system, the browser
must come with a Java Runtime Environment version 1.1 or higher. If the browser
has no Java support (such as on a small handheld device), you are still able to
maintain your remote host system using the administration forms displayed by the
browser itself. The recommended environment is Sun JVM 1.4.
Host: one PC or server or a traditional KVM switch
2.3 Installation Procedures
1. Connect the power supply to IKVM-1000.
2. Connect a monitor to the VGA connector in LOCAL CONSOLE side.
3. Connect a keyboard to the purple PS/2 connector in LOCAL CONSOLE side.
4. Connect a mouse to the green PS/2 connector in LOCAL CONSOLE side.
For Single PC or Server Conncention
5. Connect a VGA cable (15-pin HDDB Male / Male) with the Male side to both
of the PC and the HOST side of the IKVM-1000.
6. Connect one end to the PS/2 mouse port on the computer, and the other end
to the green PS/2 connector on the HOST side of IKVM-1000.
