Connecting with video equipment
Connecting HDMI devices
You should use an HDMI cable when making connection between the projector and HDMI
devices.
You should also connect the separate audio cable to a suitable audio amplifier.
Connecting RGBHV devices
Use a RGBHV video cable with 5 BNC male connectors for connection. Be sure to match the
corresponding colors between the cables and the terminals.
Connecting component-video devices
Be sure to match the corresponding colors between the cables and the terminals.
The RCA type component video sockets are provided for connection to video output
devices. If you have a BNC type component video cable, you can alternatively connect
through the BNC component video sockets.
You should also connect the separate audio cable to a suitable audio amplifier.
HDMI cable
From audio output
terminals
To audio input
terminals
HDMI device: DVD player, digital tuner, etc.
From audio output
terminals
To audio input
terminals
AV equipment: DVD player, digital tuner, etc.
BNC cable
AV equipment: DVD player, digital tuner, etc.
From audio output
terminals
To audio input
terminals
Component cable
or
