Replacement Procedures
4.16 Application for Thermal Pad on North Bridge, VGA and VRAM
I. For Satellite M300, Satellite Pro M300, Satellite L310, Satellite Pro L310, EQUIUM M300,
SATEGO M300 (Intel without VGA board) , use Thermal Pad FSL-BS75 on North Bridge
1.Thermal Pad FSL-BS75
2. one Syringe contains 12mmX14mmX0.75mm
TSB P/N Raw Material Classification Description
A000026940
JXBU2013010
NORTH BRIDGE THERMAL
PAD
THERMAL PAD UMA FSL-BS
BU2(JXBU2013,R3A)
Figure 4-34 Thermal Pad on North bridge(Intel without VGA board)
II. For Satellite M300, Satellite Pro M300, Satellite L310, Satellite Pro L310, EQUIUM
M300, SATEGO M300 (Intel with VGA board) , use following Thermal Pad on North
Bridge, and a VGA and VRAM.
1.Thermal Pad T-Flex320
2. one Syringe contains 12mmX14mmX0.5mm
TSB P/N Raw Material Classification Description
A000026950
JXTE1026010
NORTH BRIDGE THERMAL
PAD
THERMAL PAD DIS TE1(JXTE1026,R3A)
Satellite M300 and Satellite Pro M300 Maintenance Manual (960-Q08)
55
