Pin Assignment
Satellite M300 and Satellite Pro M300 Maintenance Manual (960-Q08)
22
141 M_A_DQ40 I/O 142 M_A_DQ45 I/O
143 M_A_DQ41 I/O 144 GND ---
145 GND --- 146 M_A_DQS#5 I/O
147 M_A_DM5 I 148 M_A_DQS5 I/O
149 GND --- 150 GND ---
151 M_A_DQ42 I/O 152 M_A_DQ43 I/O
153 M_A_DQ46 I/O 154 M_A_DQ47 I/O
155 GND --- 156 GND ---
157 M_A_DQ53 I/O 158 M_A_DQ48 I/O
159 M_A_DQ49 I/O 160 M_A_DQ52 I/O
161 GND --- 162 GND ---
163 NC --- 164 M_CLK_DDR1 I
165 GND --- 166 M_CLK_DDR#1 I
167 M_A_DQS#6 I/O 168 GND ---
169 M_A_DQS6 I/O 170 M_A_DM6 I
171 GND --- 172 GND ---
173 M_A_DQ50 I/O 174 M_A_DQ54 I/O
175 M_A_DQ51 I/O 176 M_A_DQ55 I/O
177 GND --- 178 GND ---
179 M_A_DQ56 I/O 180 M_A_DQ61 I/O
181 M_A_DQ60 I/O 182 M_A_DQ57 I/O
183 GND --- 184 GND ---
185 M_A_DM7 I 186 M_A_DQS#7 I/O
