Hometabtoapply2tothetextthatyouwanttoappearhere. 4ReplacementProcedures
SatelliteL550MaintenanceManual 4-17
InstallingtheODDBayModule
InstalltheODDbaymoduleaccordingtothefollowingprocedures.
1. PlacetheODDbaymoduleinthecorrectpositionandslideitin.
2. Pushitinuntilitmeetstheend.
3. SecuretheODDbaymodulewithoneM2.5x6screw.
DisassemblingtheODDDrive
NOTE:DonotdisassembletheODDdrivewhenitisworkingnormally.Disassembleor
replacetheODDdriveonlyifitfails.
DisassembletheODDdriveaccordingtothefollowingproceduresandFigure4.7.
1. RemovetwoM2x3
screws.
2. Removethebracket.
Figure4.7RemovingthebracketfromtheODDdrive
M2x3*2
