Actiontec 54 Mbps Wireless DSL Gateway User Manual
3
Chapter 1 Introduction
Minimum System Requirements
s Active DSL service
s Computer with an 10 Mbps or 10/100 Mbps Ethernet connection, or USB
connection
s Microsoft Windows 98 Second Edition (SE), Windows Millennium Edition
(Me), Windows NT 4.0, Windows 2000, Windows XP, Mac OS 7.1+, Mac OS
8.0+, Mac OS 9.0+, or Mac OS X+
☞
Note: USB LAN port is not supported with Microsoft
Windows NT 4.0 or Mac OS.
s Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator
4.0 or higher (4.7 recommended)
s TCP/IP network protocol installed on each computer
Features
s Plug-and-Play installation support for computers running Windows oper-
ating systems (98SE, Me, 2000 and XP)
s ADSL WAN port (RJ-11)
s Full-rate ANSI T1.413 Issue 2, ITU G.992.1(G.dmt) and G.992.2(G.lite)
standard compliance
s Auto-handshake for different ADSL flavors
s USB 1.1 device specification compliance
s 12 Mbps USB data rate (full speed) support
s Bridged Ethernet over ATM, PPP over ATM, PPP over Ethernet
s Precise ATM traffic shaping
s IP packet routing and transparent bridge
s RIP-1, RIP-2, and static routing protocol support
s Built-in NAT, DHCP server
s DNS relay support
