Actiontec 54 Mbps Wireless DSL Gateway User Manual
9. Enter the following address in the “IP Address” text box:
192.168.1.2
Enter the periods in the address by pressing the space bar on the keyboard.
10. Enter the following address in the “Subnet mask” text box:
255.255.255.0
Enter the periods in the address by pressing the space bar on the keyboard.
11. Click OK. The Internet Protocol (TCP/IP) Properties window disappears.
12 In the Local Area Connection Properties window, click Close. The Local Area
Connection Properties window disappears.
13. Click Close in the Local Area Connection Status window. The window
disappears.
14. Close the Network and Dial-up Connections window by clicking on the “x
button at the upper right corner of the window.
The computer restarts. It is now set up with a static IP address, allowing the user to
access the Gateway’s Web Configuration Utilities (Advanced Setup, Utilities, etc.).
