Chapter 8 Specifications
Supplemental Characteristics
159
8
Supplemental Characteristics
Output Programming Range (maximum programmable values)
Low range 0 to 15.45 V/0 to 7.21A
High range 0 to 30.9 V/0 to 4.12 A
OVP 1 V to 32 V
OCP 0 A to 7.5 A
Remote Sensing Capability
Voltage drop Up to 1 V per each lead
Load regulation Add 5 mV to spec for each 1-volt change in the + output
lead due to load current changes.
Load voltage Subtract voltage drop in load leads from specified output
voltage rating.
Temperature Coefficient, ±(% of output + offset)
Maximum change in output/readback per °C after a 30-minute warm-up
Voltage 0.01% + 3 mV
Current 0.02% + 3 mA
Stability, ±(% of output + offset)
Following 1 hour warm-up, change in output over 8 hours under constant load, line,
and ambient temperature
Voltage 0.02% + 1 mV
Current 0.1% + 1 mA
Voltage Programming Speed
Maximum time required for output voltage to settle within 1% of its total excursion (for
resistive load). Excludes command processing time.
Full load
No laod
Up 50 msec 20 msec
Down 45 msec 400 msec
