VTM-D15/A 15" MultiMedia Touch Panel Systems
AXB-TPI/3 Specifications
The following table lists the specifications for the AXB-TPI/3 and its related input modules.
Specifications
Dimensions (HWD): 3.47" x 13.75" x 8.38" (8.81 cm x 34.93 cm x 21.29 cm)
• With brackets installed for rack-mounting: 3.47" x 19.00" x 8.38"
(8.81 cm x 48.26 cm x 21.29 cm)
• With brackets rotated 45° for under/over/vertical surface mounting:
3.85" x 19.00" x 8.38" (9.78 cm x 48.2 cm x 21.29 cm)
Front Panel:
Output Resolution LEDs 3 red LEDs indicate the output video resolution:
• VGA LED - VGA output display resolution LED lights to indicate an active 640
x 480 (HV) resolution.
• SVGA LED - SVGA output display resolution LED lights to indicate an active
800 x 600 (HV) resolution.
• XGA LED - XGA output display resolution LED lights to indicate an active
1024 x 768 (HV) resolution.
AXlink LED Green LED indicates AXlink status. AXlink LED blinks to indicate the communi-
cation activity, power, and data status:
• One blink per second: Power is active and AXlink data communication is
functional.
• Full On: Power is active and AXlink data communication is not functional.
Program Port 4-pin AXlink data/power bus jack. This port is an RS-232 DB-9 connector
(male) that can be connected to a DB-9 port on a PC; used with serial com-
mands, SoftROM downloads, other DB-9 capable panels, and to upload/down-
load touch panel page information from the TPDesign3 program.
Touch Drivers Downloadable touch drivers allow you to add to the standard list of available
drivers. Currently supports devices such as the VTM-D15/A and
Elo Intellitouch
®
touch monitors.
Current Consumption • 630 mA - with no input modules (cards) only supplying power to the TPI/3
• 1.13 A - with 1 input module/card - 500 mA input module
• 1.63 A - with 2 input modules/card - 500 mA input module
• 2.13 A - with 3 input modules/card - 500 mA input module
Memory Standard 9 MB (8 MB flash)
Font Support Unicode font support. Buttons with Unicode fonts can only be created and
edited with the TPDesign3 Touch Panel Program (Version 3.16 or higher).
Slots Equipped with any combination of input modules (S-Video/Composite, VGA,
and RGB).
Outputs VGA, HD-15, and RGB 5-BNC
