VTM-D15/A 15" MultiMedia Touch Panel Systems
Specifications (Cont.)
Input Signal:
Horizontal Frequency 31 kHz - 60 kHz
Vertical Frequency 50 Hz - 75 Hz
Maximum Pixel Clock 80 MHz
Front Panel Features:
Power Switch Turns the display On and Off
LED Indicator • Lights-up green when the display is turned On
• Lights up orange when the display is in power-save mode
AUTO Button Adjusts the picture position and performance automatically
UP Button Activates the On-Screen Display menu and moves the menu cursor clockwise
to select menu items.
DOWN Button Activates the On-Screen Display menu and moves the menu cursor counter-
clockwise to select menu items.
Increase Button Activates the On-Screen Display menu. Selects the menu items and adjusts
their features (increases values).
Decrease Button Activates the On-Screen Display menu. Selects the menu items and adjusts
their features (decreases values).
Rear Panel Connectors:
VGA Analog Input 15-pin Mini D-Sub (DB-15) connector for input of VGA signals
TouchScreen Signal Cable 8-pin Mini Din to 9-pin (DB-9) connector for TouchScreen signal communica-
tion between the panel and computer through COM1 or COM2.
PWR 12 VDC 3-pin AC plug provides power to the display. Supplied by connecting
the Power Adapter and Power Cord.
Fold Switch Locks and unlocks the display into an upright position. The adjustable position
works by using the Support Bracket to fix the visible angle of the TouchScreen.
Tilt Angle 10° (degrees from vertical)
User Presets:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
• 640 x 350 31.5 KHz 70 Hz IBM VGA
• 640 x 480 31.5 KHz 60 Hz IBM VGA
• 640 x 480 35.0 KHz 67 Hz Macintosh
• 640 x 480 37.9 KHz 72 Hz VGA/72
• 640 x 480 37.5 KHz 75 Hz VGA/75
• 720 x 400 31.5 KHz 70 Hz IBM VGA
• 800 x 600 35.2 KHz 56 Hz SVGA/56
• 800 x 600 37.9 KHz 60 Hz SVGA/60
• 800 x 600 48.1 KHz 72 Hz SVGA/72
• 800 x 600 46.9 KHz 75 Hz SVGA/75
• 832 x 624 49.7 KHz 75 Hz Macintosh
• 1024 x 768 48.4 KHz 60 Hz XGA/60
• 1024 x 768 56.5 KHz 70 Hz XGA/70
• 1024 x 768 60.0 KHz 75 Hz XGA/75
Environmental:
Operating Temperature 0° C to 40° C (32° F to 104° F)
Storage Temperature -20° to 50° C (-4° F to 122° F)
Operating Accessories 10% to 90%
Storage Humidity 10% to 90%
Accessories Refer to the MultiMedia System Components section on page 1 for more
information
