VTM-D15/A 15" MultiMedia Touch Panel Systems
Specifications (Cont.)
Input resolution and refresh
rates per resolution (RGB
and VGA only)
• 640 x 480 (VGA): 60 Hz, 72 Hz, 75 Hz, 85 Hz
• 800 x 600 (SVGA): 56 Hz, 60 Hz, 72 Hz, 75 Hz
• 1024 x 768 (XGA): 60 Hz, 70 Hz, 75 Hz, 85 Hz
TPI/3 Programming • Serial connection: Connect a DB-9 cable from your PCCOM port to the
Program port located on the front of the AXB-TPI/3. This is the only method
of programming the TPI/3 using Serial Commands.
• AXlink connection: Connect a DB-9 cable from your PCCOM port to the
Programming port on the Controller. Then use an AXlink cable to connect the
AXlink connector on the Controller to the AXlink connector at the rear of the
AXB-TPI/3. This is the only method of programming the interface unit using
Send_Commands.
Included Accessories • Two rack-mount ears and a package of rack screws
• One 4-pin AXlink connector
• One 2-pin PWR connector
Optional • PSN6.5 power supply (12 VDC)
• Input module (TP3-VID, TP3-RGB, and TP3-VGA)
Input resolution and refresh
rates per resolution (RGB
and VGA only)
• 640 x 480 (VGA): 60 Hz, 72 Hz, 75 Hz, 85 Hz
• 800 x 600 (SVGA): 56 Hz, 60 Hz, 72 Hz, 75 Hz
• 1024 x 768 (XGA): 60 Hz, 70 Hz, 75 Hz, 85 Hz
TPI/3 Programming • Serial connection: Connect a DB-9 cable from your PCCOM port to the
Program port located on the front of the AXB-TPI/3. This is the only method
of programming the TPI/3 using Serial Commands.
• AXlink connection: Connect a DB-9 cable from your PCCOM port to the
Programming port on the Controller. Then use an AXlink cable to connect the
AXlink connector on the Controller to the AXlink connector at the rear of the
AXB-TPI/3. This is the only method of programming the interface unit using
Send_Commands.
Included Accessories • Two rack-mount ears and a package of rack screws
• One 4-pin AXlink connector
• One 2-pin PWR connector
Weight 4.85 lbs (2.20 kg)
