AXIS 540/640 User’s Manual Appendix C: Technical Specifications
159
Network Management SNMP-MIB II compliant (over UDP/IP and IPX), host resource MIB
compliant (over UDP/IP and IPX), private enterprise MIB included. LAN
Network Manager for OS/2. Print server status in NWAdmin/PCONSOLE.
Hardware 32 bit RISC Controller, 1 Mbyte Flash memory. 256 kbytes RAM.
Logical Connection
AXIS 540+/542+ Running simultaneously any combination of the supported protocols. Use of
IEEE802.2, IEEE802.3, SNAP and Ethernet II frame types simultaneously.
AXIS 640/642 Running simultaneously any combination of the supported protocols. Use of
IEEE802.2 and IEEE802.5 (with Early Token release support for 16 Mbps),
frame types simultaneously
Attachments
AXIS 540+ 10baseT (Twisted Pair) Ethernet
AXIS 542+ 10base2 (Thin) Ethernet
AXIS 640 Media Type 3/RJ45/UTP. Support for 4 and 16 Mbps Token Ring networks
AXIS 642 Media Type 1/DB9/STP. Support for 4 and 16 Mbps Token Ring networks
Security
UNIX: Root password. User access list and printer access.
NetWare: Encrypted passwords.
Logical Printers The logical printer ports can be programmed to perform auto ASCII to
PostScript conversion, string before and after job, string substitution and
character set conversion.
Parallel Printer One IEEE 1284 compliant high-speed parallel port, 36-pin Centronics
connector. Sustained throughput of up to 400 kbytes/s using NetWare. Bi-
directional support for Apple, Reverse Telnet, PROS. ECP support.
Front Panel 2 LED indicators: Power and Network.
Test button for information printouts.
Slide switch for Token Ring speed (AXIS 640/642 only)
