Changing DSmobileCapture scan settings (for Macintosh)
Image settings
Click the Image tab to choose image type and to set several basic scan settings.
NOTE
This image is from the DS-920DW.
(1) Image Selection Box Choose the type of document you want to scan.
(2) Duplex (DS-920DW only) Select the Duplex check box to perform Duplex (2 side) scan-
ning.
(3) Brightness Adjusts the lightness or darkness of an image. The range is from -100 to +100. The
factory default is 0.
(4) Contrast Adjusts the range between the darkest and the lightest shades in the image. The
range is from -100 to +100. The factory default is 0.
(5) Resolution Determine the quality of the scanned image. The factory default is 200 dpi.
(6) Invert Reverse the brightness and the colors in the image.
(7) Page Size Page Size allows you to capture a portion of the scanned document. Choose your
paper size from the Page Size pop-up list.
(8) Profiles Save or change the scanning setting in the dialog box of Scanner Properties.
(9) Default Reset values in this and all other Properties tabs to the original factory settings.
(1)
(7)
(8)
(3)
(4)
(5)
(6)
(10)
(9)
(2)
