— 38 —
8.1.4 Drive Circuit
8.2 Specifications of the Power Connector
The following shows the power connector from the dedicated AC adapter.
Pin configuration of Power connector
(Pin number and function)
Power connector: TCS7960-53-2010 (Hosiden) or equivalent
Applicable connector: TCP8927-63-1100 (Hosiden) or equivalent
TCP8927-53-1100 (Hosiden) or equivalent
+24V
N.C
GNDFG
1
3
2
VDR
1
2
3
4
5
6
+5V
