Epson Stylus CX7000F Series
16 10/06
Note:
You’ll also see a low ink or cartridge replacement message on your
computer screen when you print from your computer.
If a cartridge is more than six months old, print quality may decline. If
necessary, try cleaning the print head (see page 15). If printouts still
do not look their best, you may need to replace the cartridge.
Removing and Installing Ink Cartridges
Note:
Leave the expended cartridge installed until you have obtained a
replacement or the ink remaining in the print head nozzles may dry
out.
Make sure you have a new ink cartridge before you begin. Once you
start replacing a cartridge, you must complete all the steps in one
session.
Do not open ink cartridge packages until you are ready to install the
ink. Cartridges are vacuum packed to maintain reliability.
If you remove a cartridge that is low (for which you have received an
“Ink low” message), you cannot reuse it.
1. Press the P On button to turn
on the CX7000F Series, or
press the y
Cancel/Back
button until you see a screen
like this:
2. Press the
Setup button. You
see this display:
3. Press the u or d button, or
press the
5 key on the numeric
keypad, to display this option:
4.
Press the x Start Color/OK button.
5. Make sure that the document cover is closed, then open the
scanner.
Caution:
Do not open the scanner when the document cover is open.
Do not move the print head by hand; this may damage the
CX7000F Series. Always select 5.Replace Cartridge from the
display to move it.
Never attempt to open the cartridge cover when the print head is
moving. Wait until the cartridges have moved to the replacement
position.
6. Open the cartridge cover.
7. Squeeze the tab at the back of the cartridge and lift it
straight out. Dispose of it carefully. Do not take the used
cartridge apart or try to refill it.
Warning:
If ink gets on your hands, wash them thoroughly with soap and
water. If ink gets into your eyes, flush them immediately with
water.
8. Before you open the new ink cartridge package, shake it
four or five times. Then remove it from the package.
Caution:
Do not touch the green chip on the front of the cartridge. This can
damage the ink cartridge.
9. Remove the yellow tape from the bottom of the ink
cartridge.
12:00 PM Y
1.Load/Eject
5.Replace Cartri
