Host Interface
4-30 C156-E224-01EN
Sense
Key
ASC ASCQ Error description
B 4E 00 OVERLAPPED COMMAND ATTEMPTED
4 53 00 MEDIA LOAD OR EJECT FAILED
5 53 02 MEDIUM REMOVAL PREVENTED
4 83 00 THERMAL ERROR
Table 4.47 shows the format of the Sense-Key Specific field. Progress Indication
isvalidonlywhenSenseKeyisNOTREADYandtheSKSVbitis1. Otherwise,
the field is set to 00h. This field is defined for the FORMAT UNIT command
with the Immed bit set to 1.
Table 4.47 Format progress indication bytes
Bit
Byte
76543210
15 SKSV Reserved
16-17 Progress Indication
Progress Indication indicates the rate of formatting completion when the
denominator is 65536 (10000h).
INIT should not use the REQUEST SENSE command alone to
check the ODD status. Because the REQUEST SENSE command is
used by INIT to retrieve sense data that is held by the ODD on
various occasions, the contents of the sense data depend on the
results of the command executed previously.
Example: Response when the ODD is in Not Ready state
When INIT issues the TEST UNIT READY command,
the ODD ends processing with Check Condition Status
and responds to the REQUEST SENSE command with
Not Ready Sense Data. When the INIT issues the
INQUIRY command, the ODD responds with Inquiry
Data and ends processing with Good status. If INIT
continuously issues the REQUEST SENSE command,
the ODD responds with No Sense because the previous
command has ended normally and the ODD holds no
sense data.
