Installation Requirements
3-14 C156-E224-01EN
Table 3.3 Pin assignments
Pin No. Pin name Function
1 SCSI-ID (-) -
2 SCSI-ID1 SCSI ID1 setting *1
3 SCSI-ID (-) -
4 SCSI-ID2 SCSI ID2 setting *1
5 SCSI-ID (-) -
6 SCSI-ID4 SCSI ID4 setting *1
7 GND 0V
8 TERM SCSI Terminating resistor mode *2
9 GND 0V
10 Write Cache Mode Write cache mode *2
11 GND 0V
12 Spindle Automatic
Stop Mode
Automatic spindle stop mode *2
13 CTGIN Cartridge insertion signal *2 *3
14 EJSW Cartridge ejection signal *2 *4
15 LED (+)
16 LED (-)
Operating status LED signal *5
*1 When pins 2, 4, and 6 are used, connect each pin to SCSI-ID (-).
*2 When pins 8, 10, 12, 13, and 14 are used, connect each pin to GND.
*3 This signal indicates that a cartridge is inserted in the device. This is a TTL
level signal.
H: A cartridge is present.
L: No cartridge is present.
*4 This signal is used to instruct cartridge ejection from outside.
*5 The LED uses a forward current of 20 mA or less.
If voltage is applied to pin 14 from outside, the device may be
damaged. When using this pin, be sure to connect it to GND.
