4.6 Packet Commands
C156-E227-01EN 4-57
4.6.5.5 Removable Block Access Capabilities Page
Table 4.63 Removable Block Access Capabilities Page
Bit
Byte
76543210
0 0 0 Page Code (1Bh)
1 Page Length (0Ah)
2 SFLP SRFP Reserved
3 NCD SML Reserved TLUN
4-11 Reserved
The System Floppy Type (SFLP) bit indicates that the current device is a system
floppy disk.
The Supports Reporting progress of Format (SRFP) bit indicates that format
progress status is reported by the REQUEST SENSE command, when the
FORMAT UNIT command with the IMMED bit set to 1 is issued.
The Non CD Optical device (NCD) bit indicates that the current device is a non-
CD optical disk device.
The Single/Multiple LUN supported (SML) bit indicates that a CD device and a
non-CD optional disk device use the same LUN.
The Total LUN supported (TLUN) bit indicates the number of LUNs to support.
Removable Block Access Capabilities Page cannot be saved.
Table 4.64 Removable Block Access Capabilities variable
Bit
Byte
76543210
2 0 0 000000b
3 0 0 000b 000b
4-11 00h
