Fujitsu MCM3130AP Computer Drive User Manual



6.2 Maintenance Information
C156-E227-01EN 6-3
b) Failure status
Date of failure
System configuration
Environment conditions (temperature, humidity, supply voltage, etc.)
c) Failure history
d) Failure description
Description of failure
Issued commands and specified parameters
Sense data
Other error analysis information
Data loss: For a repair request, you normally do not need to
include any optical disk cartridge with an optical disk drive.
However, you do need to include a cartridge if errors keep occurring
with a specific cartridge. In such a case, be sure to save data stored
in the cartridge before sending it in. Fujitsu shall bear no
responsibility for any data lost during service or repair.
See Section 5.3.3, "Precautions" for information on packing and handling a drive
when you send it to Fujitsu.
6.2.2 Revision number
The revision number of an optical disk drive is represented with an alphabetic
character followed by a single-digit number. The revision number is shown on a
revision label attached to the drive. For example, Figure 6.1 shows the format of a
revision label.
Figure 6.1 Revision label
Revision number
