Table 4.68 Timer & Protect Page variable
Bit
Byte
76543210
2 00h
30h Fh
4 000000b 0 0
5-7 00h
Table 4.69 Timer & Protect Page default value
Bit
Byte
76543210
2 00h
30h Fh
4 000000b 0 0
5-7 00h
4.6.6 MODE SENSE (10) command
Table 4.70 MODE SENSE (10) command
Bit
Byte
76543210
0 Operation Code (5Ah)
1 Logical Unit Number Reserved DBD Reserved
2 PC Page Code
3-6 Reserved
7-8 Allocation Length
9-11 Reserved
This command transfers the mode parameter list to the host. Table 4.72 shows the
mode parameter list format.
When the Disable Block Descriptors (DBD) bit is 1, the block descriptor is not
returned. When the DBD bit is 0, the block descriptor is returned.
Allocation Length indicates the number of bytes of the mode parameter to transfer.
When Allocation Length is 0, the command ends normally without transferring
any data.
