C156-E227-01EN 3-1
CHAPTER 3 Installation Requirements
This chapter describes environmental, mounting, power supply, and connection
requirements.
3.1 Environmental Requirements
The optical disk drive must be installed in an environment complying with the
ambient environmental requirements defined in Section 2.1.3.
3.1.1 Temperature measurement points
While the drive is operating, the ambient temperatures measured 3 cm away from
the surfaces of the optical disk drive must satisfy the ambient environmental
requirements specified in Section 2.1.3. As for the surface temperatures during
operation, the contact temperatures measured at the points shown in Figure 3.1
must satisfy the temperature requirements specified in Section 3.1.2.
3.1 Environmental Requirements
3.2 Mounting Requirements
3.3 Power supply Requirements
3.4 Cable Connections
3.5 Jumper Settings
3.6 Precautions on Handling the Drive
3.7 Mounting the Drive
3.8 Cable Connections
3.9 Post-installation Operation Check and Preparation for Use
3.10 Demountin
g
the Drive
