3.11.38.2 System
CLK
Clock provides timing for all transactions on PCI and is an input to every PCI device.
All other PCI signals, except RST#, INTA#, INTB#, INTC#, and INTD#, are sampled
on the rising edge of CLK and all other timing parameters are defined with respect to
this edge. PCI operates up to 33 MHz or 66 MHz and, in general, the minimum
frequency is DC (0 Hz).
RST#
Reset is used to bring PCI-specific registers, sequencers, and signals to a consistent
state. What effect RST# has on a device beyond the PCI sequencer is beyond the
scope of this specification, except for reset states of required PCI configuration
registers. Anytime RST# is asserted, all PCI output signals must be driven to their
benign state. In general, this means they must be asynchronously tri-stated. SERR#
(open drain) is floated. REQ# and GNT# must both be tri-stated (they cannot be
driven low or high during reset). To prevent AD, C/BE#, and PAR signals from
floating during reset, the central resource may drive these lines during reset (bus
parking) but only to a logic low level–they may not be driven high. RST# may be
asynchronous to CLK when asserted or deasserted. Although asynchronous,
deassertion is guaranteed to be a clean, bounce-free edge. Except for configuration
accesses, only devices that are required to boot the system will respond after reset.
