4. Loosen the screws 1 , then remove the cover 2 .
5. If a tool for removing connectors is included in the package with the new card, use it to disconnect the
cables from the card. If no such tool is included, disconnect the cables by picking up the connectors
with your ngers and gently unplugging them.
Note: Depending on the system conguration of your computer, the card might have only one connector.
6. Remove the screw 1 . The card with the bracket pops up 2 .
Chapter 6. Replacing devices 89
