CE-05171N page 27 of 44
66..33..77 GGeenneerraall TTiimmeerr SSeettuupp
User may edit all general purpose timers. Generally, global timers
affect engine operation. They also help define an event.
aa))
B1: All event types can be associated with, and locked out
by, a Bx timer. B1 is the first global timer used for delaying
an event condition detection. The timer starts in a running
State (10 – 13) depending on which have been marked ‘In
Use’. B1 is also known as the “Lockout Timer.”
bb))
B2: The second global timer used for delaying an event
condition detection. B2 is also known as a secondary
“Lockout Timer.”
cc))
C: The delay allowing a clear reading before beginning
testing for the arming of Class C events. The default and
typical time for most applications is 2 seconds.
dd))
S: Users have up to five (5) options to assign additional
special global timers to signals. The Sx timers begin con-
currently with the Bx timers.
ee))
No Flow: The global delay used for delaying the triggering of
a No Flow event. This global no flow timer is enabled after
B1 expires, and begins timing after any of the no flow transi-
tion times configured in the digital input dialog expires.
ff))
Test: Time given to allow for maintenance testing of end
devices without triggering a fault or shutdown condition.
The timer initiates when switched to test mode.
gg))
Ignition Off Delay: Time delay before the assigned ignition
output turns off. This is typically used to burn remaining
fuel vapors after the fuel valve is turned off.
hh))
Ignition On Delay: Time delay before the assigned ignition
output turns on. This is typically used to delay ignition
until engine crank rollover can occur.
ii))
Fuel On Delay: Time delay before the assigned fuel valve
output is turns on. This is typically used to delay fuel until
ignition has been turned on.
TM
C
C
C
General Timer Setup Screen
___________________________________
▼▼
GENERAL TIMER SETUP
B1 TIMER
B2 TIMER
C TIMER
S1 TIMER
S2 TIMER
(0 - 999) 00060
▼▲ ENTER-EDIT
MORE MENU
___________________________________
___________________________________
