38
Keyboard Windows 95 keyboard (for U.S.A.: 87 keys, for U.K.: 88 keys)
Floppy Disk Drive 720 KB/1.44 MB (two-mode)
PC Card Slots Two Type I or Type II, or one Type III
Allowable current 3.3 V: 400 mA, 5 V: 400 mA,
Slots (total for two slots) 12 V: 120 mA
RAM Module Slot 144-pin, 3.3-V, SO-DIMM
Multimedia Pocket One slot (floppy disk drive included)
Parallel Port Dsub 25-pin female
Ext. Display Port Mini Dsub 15-pin female
Serial Port Dsub 9-pin male
Microphone Jack Miniature jack, 3.5 DIA
Input impedance 600 Ω, Input voltage range 0.01 Vp-p
Headphone Jack Miniature jack, 3.5 DIA
Impedance 32 Ω, Output Power 3mW (Impedance 32 Ω) X 2
Interface Infrared Communication Port Data transmission speed:
CF-35PJJ8C
*
M/CF-35PJJ8C
*
E: 4 Mbps
For all other models: 115.2 kbps
Ext. Keyboard/Mouse Port Mini DIN 6-pin female
Expansion Bus Connector Dedicated 100-pin female
Speakers Stereo Speakers (built in)
Sound 16 bits, 44.1 kHz PCM/FM sound (Sound Blaster PRO Compatible)
Operating System Microsoft
®
Windows
®
95 (FAT32 File System)
Software Utility Programs Diagnostics program, TranXit program,
PhoenixCard Manager program
Battery Pack Lithium Ion 10.8 V, 3300 mAh
Operating Time Approx. 2.5 - 5.0 hours*
Battery Charging Time Power On Approx. 4.5 hours*
Power Off Approx. 2.5 hours*
Clock Battery Coin type lithium battery 3.0 V
Operating Time Approx. 10 years
AC Adapter Input 100 -240 V AC, 50 / 60 Hz Output 15.1 V DC, 2.6 A
Power Consumption Approx. 35 W** (maximum when recharging in the OFF state)
Physical Dimensions (W X H X D) 297 mm X 37.5 mm X 230 mm (11.7" X 1.5" X 9.1")
Weight Approx. 2.2 kg (Approx. 4.9 lbs) (With the floppy disk drive installed)
Main Specifications
Specifications
Model No. CF-35PJJ8CAM/CF-35PJJ8CAE CF-35KJF4BAM/CF-35KJF4BAE
CPU Pentium
®
Processor with MMX
TM
technology Pentium
®
Processor with MMX
TM
technology
200 MHz 150 MHz
Cache Memory (second cache memory) 32 KB (256 KB) 32 KB (256 KB)
EDO Memory (Expandable to) 32 MB (96 MB Max. ) 16 MB (80 MB Max. )
Video Memory 1.1 MB 1.1 MB
LCD Type 12.1" (TFT) 12.1" (TFT)
Displayed 640 X 480 dots 256/65536/262144 colors 256/65536/262144 colors
Colors 800 X 600 dots 256/65536 colors 256/65536 colors
Hard Disk Drive (including about 110 MB 3GB* 2GB*
used specifically by the system)
*
1GB = 10
9
bytes
Other Specifications
Green Lit when the corresponding modes have been set.
Green Lit during access of the corresponding devices.
Battery Status
Green Power On
(Caps Lock) (Num Lock) (Scroll Lock) (Key Pad)
(CD-ROM) (FDD) (HDD)
LED Indicators (located below the display; explanation is from the left side) CF-35 series Quick Guide
* Varies depending on the usage conditions.
** Approx. 1.1 W when the battery pack is fully charged (or not being charged) and the computer is OFF.
