55
LAN
Enabling/Disabling the Wake Up from LAN function
When the Wake Up from LAN function is enabled, the computer automatically resumes from sleep or hibernation when the
computer is accessed from the network server via the internal LAN port. (Default setting)
The Wake Up from LAN function can be switched to enable/disable by performing the following procedure.
1 Click (Start) - [Computer] - [System properties] - [Device Manager].
z A standard user needs to enter an administrator password.
2 Double-click [Network adapters] - [Intel(R) 82566MM Gigabit Network Connection], and
click [Power Management].
3 Select the setting for [Allow the computer to turn off this device to save power] and
[Allow this device to wake the computer], and click [OK].
We recommend you to make the above two settings ON/OFF simultaneously.
NOTE
z The computer may start up if accessed by another computer on the network.
The following procedure can be used to prevent startup due to unintentional access by a computer.
A Click (Start) - [Computer] - [System properties] - [Device Manager].
z A standard user needs to enter an administrator password.
B Double-click [Network adapters], and double-click the internal network adaptor.
C Click [Power Management], add a check mark for [Allow this device to wake the computer] - [Only allow
management stations to wake the computer], and then click [OK].
