7 REMOTE CONTROL
The remote control transmits commands to the system by
infrared signals.
There are three infrared sensors, one at the front of the Projector,
one at the rear of the Projector and one on the front panel of the
DigiOptic™ Image Processor.
It is possible to control the projector by pointing the remote
control at the screen; the sensor at the front of the projector will
pick up the reflected infrared commands
(Fig. 16).
C
-
S
Y
N
C
D
V
I
Fig. 16
6 KEYBOARD PAD
Eight push buttons, at the rear of the projector, will allow complete operation without the use of the remote control.
Up/Down/Left/Right arrow keys
Navigate through and make adjustments to the On
Screen menus.
Arrow Up/Down switch on from stand-by and recall Sour
-
ce Selection menu.
Switches off to stand-
by.
Menu
Activates the On
Screen Display me
-
nus. Navigates Menu
pages.
-Focus-Esc
De-activates the On Screen Display and gives access to
the lens Zoom/Focus adjustment functions.
Auto
Selects Auto Adjust
(automatic optimisation of the di
-
splayed image).
Avoid placing obstructions between the remote control and the
infrared sensor at the front of the projector; this will impair the
remote control performance.Insert the batteries, taking care
to match the polarity, as indicated in the battery recess of the
remote (Fig. 17). Change the batteries in the remote control if
experiencing difficulty in sending commands to the projector.
If the remote control is not to be used for a long period of time
remove the batteries. Replace all batteries at the same time; do
not replace one new battery with a used battery. If the batteries
have leaked, carefully wipe the case clean and replace with
new batteries.
+
-
+
-
+
-
+
-
Fig. 17
four 1,5 V
AAA type
batteries
