26
MEMORIES
The main parameters of the image may be saved in distinct
groups of values (known as ‘Memories’); these parameters
can subsequently be applied all together by way of a single
command.
There are 3 distinct Memories (Memory 1, Memory 2, Memory
3) for each of the 25 signal types managed:
making a total of 75 different available Memories.
The image parameters that can be saved/recalled by the Me
-
mories management system are the following:
Image Picture
BRIGHTNESS ASPECT
CONTRAST COLOR TEMP.
COLOR OVERSCAN
TINT GAMMA
SHARPNESS
FILTER
SHARPNESS MODE
VIDEO TYPE
NOISE REDUCTION
5 COMP/RGB(YCrCb 15KHz) 5 COMP/RGB(RGB 15KHz)
6 COMP/RGB(YCrCb 15KHz)
6 COMP/RGB(RGB 15KHz)
5 COMP/RGB(YCrCb 32KHz) 5 COMP/RGB(RGB 32KHz)
6 COMP/RGB(YCrCb)
6 COMP/RGB(RGB)
7 COMP/RGB(YCrCb 15KHz) 7 COMP/RGB(RGB 15KHz)
8 COMP/RGB(YCrCb 15KHz)
8 COMP/RGB(RGB 15KHz)
7 COMP/RGB(YCrCb) 7 COMP/RGB(RGB)
8 COMP/RGB(YCrCb)
8 COMP/RGB(RGB)
9 GRAPHICS RGB
11 DVI-D (RGB)
12 HDMI
1 VIDEO
2 VIDEO
10 GRAPHICS RGB
11 DVI-D (YCrCb)
3 S-VIDEO
4 S-VIDEO
Some of these parameters may not be available for certain
inputs or certain input signals, as indicated in Tables 4 and 5.
The menu page for the Memories management functions is
activated by pressing the
key on the remote control or the
fl key on the keypad (Fig.30).
ZOOM
Fig.30
The operations that can be performed on each memory se
-
lected are described here below.
SAVE A MEMORY
To save the current values of the image parameters in Memory
1, use the · and ‚ keys to move to line ‘1’ and then open the pull-
down menu by pressing the
fl key (Fig.31). Then select the
option ‘Save current settings’. To confirm that the operation has
been completed successfully, the message ‘Current settings
saved in Memory 1’ is displayed at the bottom of the screen and
the letter ‘S’ appears to the left of the memory name. The same
procedure is used to save parameters in Memories 2 and 3.
0 Auto
3 S MEMORIA 1
Memories
Save current settings
Save initial settings
Rename
2 I
1 S
Fig.31
RECALL A MEMORY
To recall a Memory, select the desired line and press
‡. The
parameters saved in the selected Memory will be applied to
the image displayed and a message will appear to confirm
the operation ‘Memory 1 recalled’. The Memory recalled will
be associated with the source and signal type, and will be
automatically recalled every time that particular source and
signal type combination is selected.
