DIGIOPTIC™ IMAGE PROCESSOR
ELECTRICAL
Input signals:
• 2 COMPOSITE VIDEO (CVBS)
RCA type connectors, gold-plated
1.0 V
pp
/ 75 Ω, negative synchronisation
• 2 S-VIDEO (Y/C)
4-pin mini-DIN connectors
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [NTSC nominal burst level]
0.3 V
pp
/ 75 Ω [PAL, SECAM nominal burst level]
• 4 COMPONENTS (Y/Cr/Cb/H/V) - RGBHV
3 sets of 5 RCA connectors, gold-plated
1 set of 5 BNC type connectors, gold-plated
- Components signal
Y:
1.0 V
pp
/ 75 Ω, negative or 3-level synchronisation [HDTV]
Cr,Cb: 0.7 V
pp
/ 75 Ω
- RGB signal
R,B: 0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, separate H/V Sync or H+V Sync
1.0 V
pp
/ 75 Ω, negative or 3-level synchronisation [HDTV]
H,V: positive or negative TTL, 0.3-5 V
pp
/ 1 kΩ
• 2 RGBHV (analogue RGB)
female DB15HD connectors
R,B: 0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, separate H/V Sync or H+V Sync
1.0 V
pp
/ 75 Ω, negative or 3-level synchronisation [HDTV]
H,V: positive or negative TTL, 0.3-5 V
pp
/ 1 kΩ
• 1 DVI (digital RGB)
DVI-D female connector
• 1 HDMI™
Input/Output: 3-channel fibre optic link
Control: Remote control, via RS232 from PC or
home automation devices
Horizontal frequency: from 15 to 80 kHz (up to UXGA, 60 Hz)
Vertical frequency: 48 -100 Hz
Video standards: automatically selected (PAL B, G, H, I, M,
N, 60, SECAM, NTSC 3.58 and 4.43)
High definition video: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards: VGA, SVGA, XGA, SXGA, UXGA
Deinterlacer: Faroudja chipset, DCDi™, 3:2 pull down
sequence conversion
Control: infrared remote control, RS232 serial
(DB9 connector, female)
Outputs: - 2 12-V jack connector outputs (1 active
with system powered on, 1 active with
16:9 aspect ratio selected)
- 1 Optical S/PDIF audio output
Toslink connector
GENERAL
Power supply cable: (EU, UK and US); length 2 m
Power supply: 100 to 240 VAC, tolerance ± 10%,
frequency from 48 to 62 Hz
Peak current: 30 A max
Consumption: 30W max
Dimensions: 483 x 55 x 200 mm (WxHxD); compatible
with 19” rack
Weight (approx.): 2.5 kg
Operating Temperature: 10 to 35 °C
Transportation temperature: -15 to 55 °C
Storage temperature: -15 to 55 °C
Humidity: 20% to 95% non-condensing
Safety: EN 60950, UL 60950
Transportability: desktop equipment
Electromagnetic
compatibility: EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
Transport: IEC 68-2-31, IEC 68-2-32
LINK CABLE
Composition: three 50/125 μm multimode optical fibre
cables
Connectors: LC type
Length: 20.0±0.2m
Diameter: 5 mm max
Tensile strength: 1200N*
Type Approval: UL OFNP
*traction applied on outer cable, not on fibre cores or con
-
nectors.
