Appendix E: Printer Control Codes / Annexe E: Codes de contrôle de l'imprimante
Anhang E: Drucker-Steuercodes / Appendice E: Codici di controllo stampante
Print Pitch Control Commands
Top/Bottom Margin and Vertical Tab Commands
Description Mode ASCII Code
Select condensed print Both
SI
Same as SI Both
ESC SI
Select one line expanded print Both
SO
Same as SO Both
ESC SO
Cancel condensed print STD
DC2
Set print pitch to pica IBM
DC2
Cancel one-line expanded print Both
DC4
Set print pitch to elite IBM
ESC :
Set print pitch to elite STD
ESC M
Set print pitch to pica STD
ESC P
Cancel proportional print IBM
ESC P00H
Select proportional print IBM
ESC P01H
Cancel expanded print Both
ESC W0
Select expanded print Both
ESC W1
Cancel proportional print STD
ESC p0
Select proportional print STD
ESC p1
Description Mode ASCII Code
Advance paper to next vertical tab position Both
VT
Select VFU channels STD
ESC /
n
Set vertical tab positions Both
ESC B
n
…NULL
Set bottom margin Both
ESC N
n
Cancel bottom margin Both
ESC O
Set all tabs to power on defaults IBM
ESC R
Set VFU in a channel STD
ESC b
n
m…NULL
Set relative vertical tab positions STD
ESC e1
n
Set vertical print position to
n
/lines STD
ESC f1
n
This appendix lists the printer’s control commands. It gives the name of each
control command, along with the applicable emulation mode (Standard, IBM,
or Both), and the applicable ASCII code.
Font and Character Set Control Commands
Description Mode ASCII Code
Select italic STD
ESC 4
Cancel italic STD
ESC 5
Select Character Set #2 Both
ESC 6
Select Character Set #1 Both
ESC 7
Select Draft resident font IBM
ESC I00H
Select 12 CPI Draft resident font IBM
ESC I01H
Select NLQ resident font IBM
ESC I02H
Select Draft resident font IBM
ESC I03H
Select Draft download font IBM
ESC I04H
Select 12 CPI Draft download font IBM
ESC I05H
Select Draft double-strike download font IBM
ESC I06H
Select NLQ download font IBM
ESC I07H
Select NLQ italic resident font IBM
ESC I0BH
Select NLQ italic download font IBM
ESC I0FH
Select international character set STD
ESC R
n
Set Code Page Both
ESC [T
Print characters from all character chart IBM
ESC \
n1
n2
Print one character from all character chart IBM
ESC ^
n
Select NLQ font Both
ESC k
n
Assign character table Both
ESC (t
Select character table Both
ESC t
n
Select /cancel NLQ print mode STD
ESC x
n
