Xerox WorkCentre PE120i System Administration Guide Page 6-25
Network Installation Using Internet Services
Test Print
To ensure Internet Services has been setup correctly a test print should be submitted from a
client workstation. Perform the following steps:
¾ Create a print-ready PostScript, PCL, or ASCII text file and save it on a client workstation.
¾ From a workstation that is connected to the Internet or an Intranet, use a Browser to
access the WorkCentre PE120i embedded HTTP Server Home Page.
¾ In the URL field, enter the IP Address of the WorkCentre PE120i.
Example: If the IP Address is 192.168.100.100, enter the following in the URL field:
http://192.168.100.100
¾ Verify that files can be sent from the workstation to the WorkCentre PE120i and that they
print.
At the CentreWare Internet Services homepage for the WorkCentre PE120i
select [Services].
Select [Job Submission] and complete displayed details.
Select the green [Start] button displayed at the bottom of the screen.
¾ The Internet Services installation process is now complete.
