Appendix D: Technical Specifications
110 AXIS 540/640 User’s Manual
Logical Connection
AXIS 540/542 Running simultaneously any combination of the supported protocols. Use of
IEEE802.2, IEEE802.3, SNAP and Ethernet II frame types simultaneously.
AXIS 640/642 Running simultaneously any combination of the supported protocols. Use of
IEEE802.2 and IEEE802.5 (with Early Token release support for 16 Mbps),
frame types simultaneously.
Attachments
AXIS 540/540+ 10baseT (Twisted Pair) Ethernet.
AXIS 542/542+ 10base2 (Thin) Ethernet.
AXIS 640 Media type 3/RJ45/UTP. Support for 4 and 16 Mbps Token Ring networks.
AXIS 642 Media type 1/DB9/STP. Support for 4 and 16 Mbps Token Ring networks.
Security
UNIX: Root password. User access list and printer access.
NetWare: Encrypted passwords.
Logical Printers The logical printer ports can be programmed to perform auto ASCII to
PostScript conversion, string before and after job, string substitution,
alternative output and character set conversion.
Parallel Printer One IEEE 1284 compliant high-speed parallel port, 36-pin Centronics
connector. Sustained throughput up to 400 kbytes/s using NetWare or LAN
Server/LAN Manager. Bi-directional support for Apple, Reverse Telnet,
PROS.
Front Panel 2 LED indicators: Power and Network.
Test button for information printouts.
Slide switch for Token Ring speed (AXIS 640/642 only).
Power Consumption Power provided by external supply
AXIS 540/540+ Maximum 170 mA at 12 VDC. (Type PS-A, 9 V, 300 mA). Power can
optionally be provided by the printer (Centronics pin 18: 5 VDC, 300 mA).
AXIS 542/542+ Maximum 170 mA at 15 VDC. (Type PS-B, 12 V, 500 mA).
AXIS 640/642: Maximum 170 mA at 15 VDC. (Type PS-B, 12 V, 500 mA). An optional
jumper enables power provided by the printer (Centronics pin 18: 5 VDC,
350 mA).
Dimensions Height x Width x Depth
AXIS 540/540+ 1.1 x 2.2 x 4.7 inches (2.7 x 5.6 x 11.8 cm)
