Section 7: Setting Up - UNIX
78 AXIS 540/640 User’s Manual
String Substitutions The string substitution function performs search and replace
operations on the print data. The primary application is to replace
printer control commands. Up to 20 string substitutions may be
specified individually for each logical printer.
All strings must be entered as hexadecimal byte values, and each match
and substitute string must be preceded by a count byte.
See Appendix A, PR1_STR String Substitutions.
Example 1:
To replace the UNIX New Line (hex
0A) with an ASCII NewLine
(hex
0D 0A) for logical printer PR1, edit the following entry in
your config file:
01 is the match string count byte (length of the match string),
0A is the match string,
02 is the substitute count byte, and
0D 0A is the substitute string.
This is the default setting for logical printers PR5 through PR8.
Example 2:
To replace the UNIX New Line (hex
0A) with an ASCII NewLine
(hex
0D 0A), and the printer command
E
C
G1 (hex 1B 47 31) with
E
C
Y (hex 1B 59) for logical printer PR2, edit the following entry
in your config file:
Note: ❏ Extensive use of string substitutions will naturally decrease the
throughput rate of the AXIS 540/640.
PR1_STR. : 01 0A 02 0D 0A
PR2_STR. : 01 0A 02 0D 0A 03 1B 47 31 02 1B 59
