Appendix B: The Parameter List
98 AXIS 540/640 User’s Manual
Editing using
FTP
The File Transfer Protocol provides another alternative for changing
the parameter settings.
UNIX, Windows and
OS/2 Workstations
Follow the step-by-step procedure below to edit the config file from
UNIX, Windows and OS/2 workstations, using FTP:
1. Log in to the AXIS 540/640 by typing the command:
ftp <host name>↵
2. Enter root as user id and pass as password.
3. Up-load the config file by typing:
get config↵
4. Edit the file using your preferred text editor.
5. Down-load the config file by typing:
put config CONFIG↵
Notes: ❏ It is important that the edited filename is specified in block
capitals. Otherwise, the edits are regarded as temporary and will
be lost once the AXIS 560/660 has been powered down.
❏ The method for performing file transfers using FTP can vary,
dependent upon which FTP application you are using.
Editing from a
Macintosh
To edit the config file from a Macintosh you will need FTP support
such as MacTCP, Fetch or Anarchie. The procedure for doing this is
the same as described for UNIX above.
Printing parameters
on the printer
The current parameter list may output to a printer connected to the
AXIS 540/640 by double-clicking the Test button.
