8-/16-/24-Port 10/100 PoE PSE Web Smart Switch
724-746-5500 l www.blackbox.com
6
1. Specifications
Hardware Specifications
Buffer Memory: LPB708A, LPB716A: Embedded 1625 K bits frame buffer;
LPB724A: 2750 K bits
Certifications: FCC Class A, CE
Flow Control: IEEE802.3x compliant for full duplex;
Backpressure flow control for half duplex
Full Forwarding/Filtering Packet Rate: PPS (packets per second):
Forwarding Rate Speed
148,800 PPS 100 Mbps
14,880 PPS 10 Mbps
MAC Address and Self-learning: 4K MAC address
Network Interface: 8-port/ 16-port/ 24-port 10/100BaseT(X) with PoE (half/full power);
2-port combo UTP/SFP Gigabit (LPB724A only)
Standards Compliance: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3x Flow Control, IEEE 802.3ad
Trunk, IEEE 802.3af Power over Ethernet (PoE), IEEE 802.1Q VLAN, IEEE 802.1p QoS,
IEEE 802.1x Port-based Network Access Control, IEEE 802.1d Spanning Tree Protocol,
IEEE 802.1w Rapid Spanning Tree Protocol
Switching Method: Store and forward
Transmission Media: 10BASE-T CAT3, 4, 5 UTP/STP; 100BASE-TX CAT5 UTP/STP
Transmission Mode: 10/100Mbps support full- or half-duplex
Transmission Speed: 10/100 Mbps for TP
Connectors: LPB708A: (8) RJ-45;
LPB716A: (16) RJ-45;
LPB724A: (24) RJ-45, (2) combo UTP/SFP
Indicators: LEDs: Per Port: LINK/ACT;
PoE Port: Act/Status;
Per Unit: Power
Temperature Tolerance: Operating: 32 to 131° F (0 to 55°C);
Storage Temperature: -4 to 194°F (-20 to 90 C)
Humidity Tolerance: 10 to 90% RH (non-condensing)
Power: Input: 100–240V/AC, 50–60Hz;
PoE Power Output: 15.4 Watts (Max) per port
Power Consumption: LPB708A: 130 Watts (maximum); LPB716A: 260 Watts (maximum);
LPB724A: 390 Watts (maximum)
Size: LPB708A: 1.7”H x 6.3”W x 10.5”D (4.4 x 16 x 26.6 cm);
LPB716A, LPB724A: 1.7”H x 8.7”W x 17.3”D (4.4 x 22 x 44 cm)
Weight: LPB708A: 3.5 lb. (1.6 kg); LPB716A: 7.9 lb. (3.6 kg); LPB724A: 8.6 lb. (3.9 kg)
