Routine maintenance
73
A
You must clean the machine regularly and replace the consumable items when the messages in
the table are displayed on the Touchscreen.
1
Letter or A4 size single-sided pages.
2
Approx. cartridge yield is declared in accordance with ISO/IEC 19798.
3
1 page per job
4
Drum life is approximate and may vary by type of use.
5
Standard toner cartridge
6
High yield toner cartridge
Touchscreen
messages
Consumable item
to replace
Approximate life How to replace Order No.
Replace Toner
Toner cartridge
The Touchscreen
shows the toner
cartridge color that
you must replace.
BK = Black
C = Cyan
M = Magenta
Y = Yellow
<Black>
2,500 pages
125
<Cyan, Magenta,
Yellow>
1,400 pages
125
2,200 pages
126
See page 75.
TN-221BK
5
TN-221C
5
TN-221M
5
TN-221Y
5
TN-225C
6
TN-225M
6
TN-225Y
6
Replace DrumX
Drum unit
X = BK, C, M, Y
BK = Black
C = Cyan
M = Magenta
Y = Yellow
15,000 pages
134
See page 86. 4 Drum units:
DR-221CL
1 Drum unit:
DR-221CL-BK
DR-221CL-CMY
Drum Stop Drum unit
Replace Belt Belt unit
50,000 pages
1
See page 91. BU-220CL
Replace WT Box Waste toner box
50,000 pages
1
See page 95. WT-220CL
Replace Fuser Fuser unit
50,000 pages
1
Call Brother Customer Service or your
local Brother dealer for a replacement
fuser unit.
Replace PF kit Paper feeding kit
50,000 pages
1
Call Brother Customer Service or your
local Brother dealer for a replacement
paper feeding kit.
