DVS 510 Series • Operation 21
Menu flow diagram
The flow diagram below shows the menus that are displayed in the front panel LCD window
and the order in which they appear when you repeatedly press the Menu button.
Power
On
Input
Configuration
2 sec.
Menu
Menu
Menu
30 sec.
View
Comm Setting
Menu
30 sec.
30 sec.
Default
Cycle
2 sec.
Menu
Next
Exit Menu?
Press NEXT
Menu
30 sec.
User
Presets
30 sec.
30 sec.
Menu
Extron
DVS 510 V1.00
Initializing
Please Wait...
Audio
Configuration
Menu
30 sec.
Advanced
Configuration
Output
Configuration
Figure 13. Main Menu
The following sections describe the submenu options for each of the menus.
