DVS 510 Series • Remote Configuration and Control 76
Command
ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Stream Files via Telnet, RS-232, or RS-422
Load le to user ash
memory
24,28
E +UF filesize, filename }
Upl ]
Load le to user ash and set
specific time and date
24,28
E +UF filesize*day-of-week
•month•day•year•hour•minute•second,
filename
}
Upl ]
Day-of-week = 1–7
(1 = Sunday, 2 = Monday ...)
Month = 1–12
(1 = Jan, 2 = Feb, ...)
Day = 1–31
Hour = 0–23
Minute and Second = 0–59
NOTES: If there is insufficient space on the unit to store the sent file, the response is Fld ] instead of Upl ] to denote
failure.
You can use this command to update firmware by loading a firmware file with a .S19 extension. If the unit
determines that the .s19 file is not intended for the DVS, the Upl
] response is followed by Fwm ] (firmware
mismatch).
Retrieve le from user ash
memory
24,28
E filename SF }
Responds with 4 bytes of file-size plus raw, unprocessed
data in the file.
Stream files via Port 80
Load le to user ash memory
Use a POST on port 80, followed by the delimited data to be written to the ash le
memory.
Retrieve le from user ash
memory
Send a page GET on port 80 followed by:
Ie.http://192.168.254.254/mypage.html?cmd=WSF|
Responds with raw, unprocessed data in file.
Back Up and Restore Unit Configuration
Save unit configuration (to file
system)
E 1 * configuration type XF }
Cfg1 * configuration type ]
For configuration type:
0 = IP configuration (ip.cfg)
1 = Event conguration
(event.cfg)
2 = Unit-specic parameters
(box.cfg)
The files are stored in the
directory /nortxe-backup
created on the unit by the Save
commands.
Restore unit configuration
E 0 * configuration type XF }
Cfg0 * configuration type ]
