4.6 Packet Commands
C156-E205-01EN 4-45
Table 4.47 lists the mode parameter list.
Table 4.47 Mode parameter list
Bit
Byte
76543210
0-4 Mode Parameter Header
0-7 Block Descriptor
0-n Mode Page (s)
The mode parameter list consists of a mode parameter header Block Descriptor
and Mode Page (s). Table 4.48 lists the mode parameter header.
Table 4.48 Mode parameter header
Bit
Byte
76543210
0 Mode Data Length
1 Medium Type Code
2 WP Reserved
3 Block Descriptor Length
The values specified for Mode Data Length, Medium Type Code, and WP are
ignored. Block descriptor Length must be 0 or 8.
Table 4.49 lists the block descriptors.
All the values specified for Block Descriptor are ignored.
Table 4.49 Block descriptor
Bit
Byte
76543210
0 Density Code (00h)
1-3 Number of Blocks
4Reserved
5-7 Block Length
