1 • General Information Model 3201 G.SHDSL Integrated Access Device User Guide
12 Model 3201/3241 G.SHDSL Router Modem overview
Model 3201/3241 G.SHDSL Router Modem overview
The Patton Models 3201 and 3241 router modems are G.SHDSL routers/bridges for delivering basic and
advanced IP services from the wide-area network to a local 10/100Base-T Ethernet LAN.
G.SHDSL offers an alternative, standards based DSL transmission medium. It offers connection speeds of 2.3
Mbps (Model 3201) or 4.6 Mbps (Model 3241) in each direction over a single twisted-pair (TP). Supporting
100 or more users, the router modems are optimized for users in a small office, as an enterprise tele-working
solution or for multimedia high-speed Internet access. Local and remote web-based management ensures easy
setup and continuous trouble-free operation.
The following sections describe Model 3201 and 3241 features and capabilities:
• General attributes, see page 12
• G.SHDSL Characteristics (Model 3201/3241), see page 12
• Ethernet, see page 12
• Protocol support, see page 13
• PPP support, see page 13
• ATM protocols, see page 13
• Management, see page 13
• Security, see page 13
General attributes
• Compact low-cost plug-and-play router
• 10/100 Ethernet
• Comprehensive hardware diagnostics, works with any operating system, easy maintenance and effortless
installation.
• Built-in web configuration.
• Simple software upgrade using FTP into FLASH memory.
• Eight front panel LEDs indicate Power, DSL WAN, Ethernet LAN speed and status.
• Convenient and standard RJ connectors for Ethernet, Line, and Console.
G.SHDSL Characteristics (Models 3201 and 3241)
• 2.3 Mbps (Model 3201) or 4.6 Mbps (Model 3241) speed over 2 wires.
• DTE rates:
- Model 3201: 144 kbps to 2.32 Mbps, nx64k with n=3 to 36
- Model 3241: 144 kbps to 4.6 Mbps, nxz64k n=3 to 72.
• Distance from 24,900 feet (7,589 m) at 144kbps (192 kbps line rate) to 10,200 feet (3,109 m) at 2.3 mbps
on 26 AWG (0.4 mm) wire
• CO and CP modes supported
• EOC Management channel for remote end-to-end management.
Ethernet
• Auto-sensing full-duplex 10Base-T/100Base-TX Ethernet.
• Standard RJ-45 and built-in MDI-X cross-over switch.
• IEEE 8021.d transparent learning bridge up to 1,024 addresses and Spanning Tree.
